XRay - X12 26 1/12 LMP RC PAN CAR KIT (2026) - XR370022

The XRay X12 26 delivers a focused set of 2026 updates aimed at improving stability, traction and overall drivability. Identified by part number XR370022, this latest evolution refines the chassis, suspension geometry and servo mounting to enhance consistency on the track and simplify maintenance.

A redesigned carbon layout with added access points makes rear pod servicing easier, while strengthened front-end components and a thinner front brace improve durability and feel. New mounting options let you choose between fixed and floating servo installations, with an all-new floating servo holder designed for more forgiving handling and reduced steering drift after impacts.

Key Features for 2026

• Redesigned chassis with reduced rear flex for improved stability and overall traction
• Additional chassis holes for floating servo mounting and easier access to rear pod hardware
• New pod front plate and carbon side link plates with three positions to align side links to each centre pivot setting
• Revised side link mounting keeps rear pivots in line with each centre pivot position to minimise bind during suspension compression
• Redesigned front carbon bumper for improved durability
• Thinner 1.6 mm carbon front brace to improve handling and overall feel
• New aluminium pivot holders enable a lower roll-centre setting without protruding below the chassis
• Two servo mounting alternatives: fixed and floating
• All-new floating servo holder for more forgiving handling and minimised steering drift after a crash
• Improved centre damper sealing to eliminate oil leakage
• Wider front lower arm (1 mm per side) to improve drivability in all conditions

Design Highlights

From the refined side link geometry to the lower roll-centre capability, each update on the X12 26 works together to deliver predictable grip and balanced steering. The service-friendly chassis layout and improved sealing reduce downtime, letting you focus on consistent performance run after run.
