Introducing the Hobbywing Quicrun brushed motors.

Outstanding Response and Control
The new Quicrun brushed motors offer improved performance, reliability, and response over other motors. With improved materials and overall design, these motors offer significant power gains.

Excellent efficiency
With up to 69% maximum efficiency, the Quicrun brushed motors far exceed standard motors of the same specifications (555-11T). The maximum efficiency is up to 17% higher. These new motors run cooler (Lower temps) than similar motors under the same load.

Zero Cogging Torque Design
The 555 motor adopts a 5-slot design, and the motor cogging effect is virtually eliminated. These new motors have a very small torque fluctuation and, bring a very linear response at all speeds for an improved overall drive feel.

Adjustable mechanical timing of the motor
The mechanical timing of the motor can be adjusted by -20 — 20 °. This allows users to fine-tune the RPM and feel of motors. Timing adjustments also allow the motors to be used for CCW and CW applications.

Specialized Carbon Brush for extended life
Developed specifically for these motors, the new brushes feature a custom blend to provide extremely long life, while providing great performance. These motors start to compare to brushless motors in terms of life span.

Modular design for easy service and cleaning
The motors feature an easy-to-service rebuildable design. Convenient for cleaning and maintenance, effectively prolonging the life span and maintaining the efficiency of the motor.

PCB anti-interference board
The motor is equipped with a dual PCB anti-interference board. These reduce the harmful spikes and noise from affecting your speed control.

Quality materials
To ensure high tolerance to abuse and heavy-duty driving, a 200°C high-temperature resistant magnet, 180°C high-temperature resistant copper wire has been used. Combined with 0.35 mm (only 555) ultra-thin silicon steel sheet, and the Hobbywing custom carbon brush, these motors are built to handle the demands of today's driver.

Specifications

Type

Scale - 1/10th
Brushed/Brushless - Brushed
Turns - 30T

Relevant Parameters

RMP@7.4v - 10500
Input Voltage - ≥12.6v
Slot - 3

Size & Weight

O.D.(mm) - 36
Length (mm) - 53.2
Shaft Diameter (mm) - 3.175
Weight (g) - 168

Applications - 1/10thOn-road / Buggy / Crawler & 2WD Truck

Tamiya Release Date: End of April 2024

Tamiya is delighted to announce the release of the Ford Baja Bronco as our new R/C model on the cross country CC-02 chassis. The first generation Ford Bronco was relatively compact and extremely capable off-road, and this 4WD car joined numerous races.

The Baja Bronco was sold from 1971 to 1975 to commemorate victory in a major desert race. It had a white and red body with blue roof and black hood plus reinforced sections such as suspension, and this special Bronco enjoys great popularity even in the modern day.

The 1990 Land Rover Defender 90 (originally depicted in Item 58657 on the CC-01 chassis) makes its way to the CC-02 chassis! The Defender 90 is a legendary Land Rover off-road car, and its roots go back to 1948. Based on differences in wheelbases, this car has three types – the Defender 90/110/130. This R/C model depicts a 3-door model with 93-inch wheelbase.

CC-02 Chassis - Off Road, Evolved
Designed for a wide range of off-road scenes including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with black wheels and grippy block pattern tyres.

About the Model

• 1/10 scale R/C model assembly kit. Length: 429mm, width: 200mm, height: 215mm, wheelbase (short): 242mm (CC-01S chassis)
• Polycarbonate body
• Compatible with 5mm-diameter LEDs x2 for headlights and 5mm-diameter LEDs x6 for the rear
• Includes separately moulded parts for grille, side mirrors, light cases and outer roll gages
• Black ABS resin wheels are paired with semi-pneumatic all-terrain rubber tyres
• The ladder frame CC-02 chassis features superior durability and employs front/rear coil spring suspension which is great for off-road surfaces including rocky terrain
• Includes 540 Type brushed motor
• A wide range of Hop-Up Option Parts is available to customize the CC-02 chassis

Separately Required Items

• 2-channel radio, steering servo, 7.2-7.4volt battery & charger, and Tamiya PS paint

Tamiya Release Date: 20/10/2023

The Toyota Land Cruiser 40 has been a staple subject for Tamiya since 2008. It first appeared on the CR-01 crawler chassis then later the simpler CC-01 cross country chassis. Now, the classic Land Cruiser makes its way on to Tamiya’s newest cross-country platform, CC-02 with a few detail tweaks for the scale enthusiast!

CC-02 Chassis - Off Road, Evolved
Designed for a wide range of off-road scenes including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with 12-spoke wheels and semi-pneumatic rubber tires.

• 1/10 scale R/C model assembly kit. Length: 390mm, width: 198mm, height: 237mm. Wheelbase: 252mm (M-size wheelbase).
• The CC-02 chassis is designed for a wide range of off-road driving expeditions and has a ladder frame which was inspired by full-size vehicles.
• Pre-painted  Body.
• NEW: A roof rack with light pods is realistically depicted with separately moulded parts.
• NEW: Silver colour 12-spoke wheels are paired with block pattern tires. (Wide wheels are included to recreate the customized look of this version.)
• NEW: New stickers feature integrated tinted window and window frame sections to allow ease of applying stickers and eliminate the need for painting the window tint.
• Includes Motor and ESC.
• Requires 2-channel radio, steering servo, 7.2-7.4volt battery with compatible charger.

Sock it to 'em Good!
This R/C model assembly kit recreates a rock crawling vehicle like those seen in popular U.S. events where the massive machines vie for time or crawling ability over impossible-looking obstacles. The lightweight yet tough polycarbonate racing truck body comes with a host of marking stickers for decoration. The tough CR-01 chassis is up to the rock crawling challenge, its durable ladder frames featuring aluminum side channels and resin cross members as well as a 4-link rigid suspension with oil dampers and progressive springs. The motor is placed in a central position, with planetary gears enabling low-speed shaft-driven 4WD. Front and rear differentials can be locked. Large-diameter tires feature a tread pattern which extends to the sidewalls, and are fitted to beadlock wheels.

Specifications
_Length: 435mm _Width: 265mm _Height: 215mm _Weight: 2,309g (not including R/C equipment and battery pack) _Wheelbase: 288mm _Tread (Front & Rear): 208mm _Tire Width/Diameter (Front & Rear): 57/125mm _Aluminum & Resin Ladder Frame _Shaft-Driven 4WD _Front/Rear 3-Bevel Differentials (locked as standard) _Planetary Gearbox _Front/Rear 4-Link Rigid Suspension _Front/Rear CVA Shock Units _Gear Ratio = 32.4:1 _Type 540 Motor _Requires Electronic Speed Controller (sold separately)

Separately Required Items
_2-Channel R/C Unit with ESC__Battery Pack & Charger

The Ford Bronco has been sold since 1966, and the Ford Bronco 2021 was announced, with great anticipation, as the sixth-generation model in early 2021, 25 years since the last generation’s release.

Tamiya’s design team have chosen to give R/C enthusiasts a replica of the best Bronco variant of this new generation. The R/C model assembly kit depicts the 2-door top grade First Edition model. The First Edition Bronco SUV is built for those who have waited patiently for the legend’s return. The First Edition is a loaded Bronco combining the best parts of all Bronco series. First Edition Broncos use the mechanicals of a Badlands, the interior of an Outer Banks and the exterior of a Wildtrak to create the ultimate Bronco! The Tamiya version sits on top of the CC-02 chassis for capable and fun R/C driving on the trails!

CC-02 Chassis - Off Road, Evolved
Designed for a wide range of off-road scenes including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with 12-spoke black wheels and semi-pneumatic rubber tyres.

About the Model

• 1/10 scale R/C model assembly kit. Length: 447mm, width: 204mm, height: 233mm. Wheelbase: 252mm (Medium)
• 1.2mm thick polycarbonate body
• Features PC-ABS H parts (grilles, mirrors, spare tyre cover and door handles) and metal-plated K parts (light cases)
• ABS plastic roof rack included
• The CC-02 chassis has ladder frame which was inspired by full-size vehicles, provides both rigidity and cool styling, and allows stable performance even on tricky rocky and dirt roads
• 12-spoke black wheels (width: 26mm, offset: +6) are paired with semi-pneumatic rubber tyres
• Type 540 motor and ESC included
• Requires: 2-channel radio, steering servo, 7.2volt battery with compatible charger, and Tamiya PS polycarbonate paint

Get ready to do some fun trail exploration with the all-new Tamiya CC-02 (Cross Country 2) chassis platform! Tamiya’s designers have been hard at work to bring R/C enthusiasts the next generation of Tamiya trail driving with a completely revamped machine.

The first body to grace the capable new chassis is a highly-detailed polycarbonate recreation of the Mercedes-Benz G 500, which first graced the Mercedes stable of SUV’s in 2018.

CC-02 Chassis - Off Road, Evolved
Designed for a wide range of off-road scenes including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with matte plated seven-spoke wheels and grippy block pattern tires.

• 1/10 scale R/C model assembly kit. Length: 455mm, width: 196mm, height: 207mm. Wheelbase: 267mm.

• TLU-01 LED Light Unit and LEDs included.

• G 500 body is recreated accurately in polycarbonate. Separately molded parts are included for the front grille, side mirrors and spare tire cover.

• Designed for a wide range of off-road terrain including rocky surfaces, the CC-02 chassis’ ladder frame is inspired by full-size vehicles and is the base for its superior durability.

• A 4WD setup employs the motor longitudinally behind the front axle, with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears to the front and rear.

• Twenty gear ratios between 11.09:1 and 29.28:1 are possible using separately sold pinion gears, for some serious fine-tuning!

• 4-link rigid suspension front and rear, with CVA oil dampers.

• Differential Gears: 3-bevel differential gears provide a smooth driving. They can also be locked (with reassembly) for driving on poor surfaces.

• Axle Housings: Housings enclose a central differential gear and axle shafts in a rigid setup that lets the chassis take on rough terrain with ease: if one wheel rises, the other is pushed downward to help the chassis gain traction.

• Gearbox: Power from the motor is routed via the realistic looking gearbox and transfer case, from its propeller shafts to the differential gears, and finally to the wheels.

• 4-Link Suspension: A rigid setup employs 4 plastic link arms on each axle housing and four oil dampers. This ergonomic design offers superior durability and the ground clearance.

• Includes: Tamiya TBLE-02S ESC (electronic speed control) Capable of running sensor brushless motors and brushed motors alike. (21.5 Turn BL motor limit) (23 Turn brushed motor limit.

• Required Items: 2-Channerl radio, steering servo, 7.2-7.4volt battery pack with compatible charger, and Tamiya PS paint.

Since the first generation model release in 1951, the Toyota Land Cruiser has been one of the most famous 4WD vehicles in the world. This R/C model assembly kit recreates the Land Cruiser 300 series announced in 2021. The polycarbonate body realistically depicts the eye-catching, dignified form with separate parts to capture the distinctive large front grille's horizontal fins and metal-plated sections. Light case and door mirror components are metal-plated, and door handles and shark fin antenna on the roof are rendered by separate parts for more realism. Silver colour 12-spoke wheels are paired with block pattern tyres.

CC-02 Chassis - Off Road, Evolved
Designed for a wide range of off-road scenes including rocky terrain, the CC-02 chassis' ladder frame is inspired by full-size vehicles and is the base for its superior durability. A 4WD setup employs the motor longitudinally behind the front axle with separated gearbox and transfer case, and propeller shafts transmitting power to the differential gears front and rear. Four-link rigid suspension is employed front and rear, with CVA oil dampers for all-encompassing control, even on tricky rock sections. This model comes with silver colour twelve-spoke wheels and grippy block pattern tyres.

About The Model

• Length: 472mm, width: 200mm, height: 192mm
• Wheelbase: 267mm　
• Tread: 160mm (front), 163mm (rear)
• Tyre width/diameter: 33/90mm (front & rear)
• Ladder frame
• Longitudinal motor, shaft-driven 4WD
• 3-bevel differential gears
• 4-link rigid suspension (front & rear) & CVA oil dampers
• Gear ratio = 17.33:1 (using kit-standard 16T pinion)
• Type 540 motor
• Electronic Speed Controller (ESC) is sold separately

Separately Required Items

• Two-channel radio, ESC, steering servo, 7.2-7.4volt battery with compatible charger, and Tamiya PS polycarbonate paint
