Tamiya TT02 Parts & Hop-ups

THIS SET WILL ALLOY YOU TO FIT A KIMBOROUGH HIGH TORQUE SERVO SAVER TO A TT01E. YOU MAY NEED TWO M3 BOLTS TO COMPLETE.

This aluminum center drive shaft is a must have upgrade for Tamyia TT02! It is much stiffer than the standard stock parts, and offer more power transfer to the RC Cars. This main drive shaft also comes with an o-ring to provide more aggressive steering on the front axle, especially when using front oneway.

Feature:

• For: Tamiya TT02
• Material: Aluminum
• Color: Blue

Specification:

• Length: 140mm

Include:

• Aluminum Main Drive Shaft (1 pc)
• O-Ring (1 pc)
• Manual (1 pc)

The Yeah Racing Aluminum Bearing Steering Set is an optional part to replace the stock plastic component and bearings. Yeah Racing carefully constructed the set with the high grade Aluminum to ensure the steering set durability even under hard impact. Additionally the overall rigidity and bearing smoothness is highly increased, thereby raising the driving stability and steering performance.

Feature:

• For: Tamiya TT02
• Material: Aluminum
• Color: Blue

Include:

• Steering Arm (3pcs)
• M3 x 10mm Flat Head Screw (2pcs)
• M3 x 12mm Button Head Screw (3pcs)
• M3 x 14mm Button Head Screw (2pcs)
• 5mm Screw Holder (2pcs)
• 5 x 8 x 2.5 mm Ball Bearing (4pcs)
• 3 x 6 x 2.5 mm Ball Bearing (2pcs)

This Yeah Racing Aluminum Adjustable Motor Mount #TT02-013 is specially designed for Tamiya TT02. It allows users to perfectly fit different pinion gears in. Aluminum designed motor mount can also dissipate heat and cool down the motor.

* Photos for reference only.

Feature:

• For: Tamiya TT02
• Material: Aluminum
• Color: Blue

Include:

• Aluminum Adjustable Motor Mount (1 pc)
• M3 x 6mm Screw (2 pcs)
• M3 x 8mm Screw (2 pcs)
• 3 x 6 x 1mm Washer (1 pc)
• Manual (1 pc)

This Yeah Racing Front Knuckle Arms for Tamiya TT02 are made from durable aluminum. The product has been designed to strengthen the steering system, which is a direct replacement to the stock part.

Feature:

• For: Tamiya TT02 TT02S

• Material: Aluminum

• Color: Blue

Include:

• Yeah Racing Aluminum Front Knckle Arm (2 pcs)
• M3 x 12 mm Screw (2 pcs)
• M3 x 10 mm Screw (4 pcs)
• Manual (1 pc)

Aluminum spur gear adaptor plate and spacer set for securely mounting your spur gear on your TT02, this allows for a more flat installation and prevents it from bending under hard acceleration!

Feature:

• For: Tamiya TT02
• Material: Aluminum
• Color: Blue

Include:

• Aluminium Spur Gear Adaptor (1 pc)
• Collar (1 pc)
• Screws (4 pcs)
• Pin (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P 19T (1 pc)
• Set screw (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P 19T (1 pc)
• Set screw (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P (1 pc)
• Set screw (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P 19T (1 pc)
• Set screw (1 pc)

Spring loaded quick change battery holders for Tamiya's TT01 and TT02! Highly adjustable for different types of batteries, including different height posts to use with either normal or LCG batteries! Without using tape, the chassis is not under pressure and will not tweak!

Feature:

• For: Tamiya TT01 TT02

• Material: Aluminum 7075 / Plastic

• Color: Blue/Black


Include:

• Quick Change Battery Mounts (2 pcs)

This is Alloy Wheel Adapter Set for All Tamiya 1/10 Car

Feature:

• For: All Tamiya 1/10 GP & EP Car
• Material: Aluminum
• Color: Blue

Specification:

• Thickness: 5.5mm

Include:

• Alloy Wheel Adapter (4pcs)
• Pin (4pcs)
• Set Screw (4pcs)

This item comes packaged in a labelled re-sealable bag, helping to keep storage and recognition easy.

Photo is for show only and does not depict the real product.

Assembly required! Use shock pliers and shock pump where possible! Comes with 300cst oil.

Description:

This is a Yeah Racing newly designed damper set for 1/10 RC cars. Despite the 5 stage stiffness spring sets, Yeah racing damper set featured the state of the art technology interchangeable damper piston which gives so much serious tuner so much potential to tune their damper settings. The interchangeable piston will allow 3 settings of damper's response as well as 4 rebound rate adjustment to fit different racing situation and maximum performance.

The Yeah Racing new damper set has spent great effort on increasing the durability and maintenance ease. The damper shaft is coated with titanium for minimizing friction and longer lifespan. To cope with the need to change the damper piston from time to time, the shock gear have selected premium quality anti-leak O-Ring to keep the damper oil in place. CNC machined high grade aluminum were used to build this high end damper set for maximum durability at the minimum weight.

Rebound Core System:

The Yeah Racing Aluminum damper set comes with 6 different damper piston for fine-tuning the rebound characteristics. The set of 3 general type piston allow you to adjust 3 different rebound rate where has the same depression and compression resistant. While the "V piston" featured a v shape damper oil tunnel which allows the depression rate differ from the compression rate for more precise tuning. For instance, a rear wheel drive RC can be benefit by a stiffer rear wheel compression rate to offset the weight transfer during hard acceleration while maintaining balanced depression rate throughout the whole car.

Feature:

• For: 1/10 RC Cars
• Material: Aluminum
• Color: Gun Metal
• CNC Machined
• Titanium Coated Damper Shafts
• Selected Anti-Leak O-Ring
• Unique Piston Design
• Rebound Core System
• Aluminum Damper Cylinder
• Easy To Refill Damper Oil
• Simple Installation

Specification:

• 55mm Hole to Hole

Include:

• • Shock-Gear (4 pcs)
  • Piston 2 Holes (4 pcs)
  • Piston 3 Holes (4 pcs)
  • Piston 4 Holes (4 pcs)
  • V Piston 2 Holes (4 pcs)
  • V Piston 3 Holes (4 pcs)
  • V Piston 4 Holes (4 pcs)
  • Spring Red (Super Soft) (4 pcs)
  • Spring Yellow (Soft) (4 pcs)
  • Spring Blue (Medium) (4 pcs)
  • Spring White (Hard) (4 pcs)
  • Spring Black (Super Hard) (4 pcs)
  • Ball End (8 pcs)
  • Ball Nut (4 pcs)
  • Shock Oil 300CST 15ml (1 pc)
  • Manual (1 pc)

Assembly required! Use shock pliers and shock pump where possible! Comes with 300cst oil.

Description:

This is a Yeah Racing newly designed damper set for 1/10 RC cars. Despite the 5 stage stiffness spring sets, Yeah racing damper set featured the state of the art technology interchangeable damper piston which gives so much serious tuner so much potential to tune their damper settings. The interchangeable piston will allow 3 settings of damper's response as well as 4 rebound rate adjustment to fit different racing situation and maximum performance.

The Yeah Racing new damper set has spent great effort on increasing the durability and maintenance ease. The damper shaft is coated with titanium for minimizing friction and longer lifespan. To cope with the need to change the damper piston from time to time, the shock gear have selected premium quality anti-leak O-Ring to keep the damper oil in place. CNC machined high grade aluminum were used to build this high end damper set for maximum durability at the minimum weight.

Rebound Core System:

The Yeah Racing Aluminum damper set comes with 6 different damper piston for fine-tuning the rebound characteristics. The set of 3 general type piston allow you to adjust 3 different rebound rate where has the same depression and compression resistant. While the "V piston" featured a v shape damper oil tunnel which allows the depression rate differ from the compression rate for more precise tuning. For instance, a rear wheel drive RC can be benefit by a stiffer rear wheel compression rate to offset the weight transfer during hard acceleration while maintaining balanced depression rate throughout the whole car.

Feature:

• For: 1/10 RC Cars
• Material: Aluminum
• Color: see photo
• CNC Machined
• Titanium Coated Damper Shafts
• Selected Anti-Leak O-Ring
• Unique Piston Design
• Rebound Core System
• Aluminum Damper Cylinder
• Easy To Refill Damper Oil
• Simple Installation

Specification:

• 55mm Hole to Hole

Include:

• • Shock-Gear (4 pcs)
  • Piston 2 Holes (4 pcs)
  • Piston 3 Holes (4 pcs)
  • Piston 4 Holes (4 pcs)
  • V Piston 2 Holes (4 pcs)
  • V Piston 3 Holes (4 pcs)
  • V Piston 4 Holes (4 pcs)
  • Spring Red (Super Soft) (4 pcs)
  • Spring Yellow (Soft) (4 pcs)
  • Spring Blue (Medium) (4 pcs)
  • Spring White (Hard) (4 pcs)
  • Spring Black (Super Hard) (4 pcs)
  • Ball End (8 pcs)
  • Ball Nut (4 pcs)
  • Shock Oil 300CST 15ml (1 pc)
  • Manual (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P 19T (1 pc)
• Set screw (1 pc)

Replace parts to the original motor gear/pinions for Tamiya car

(WILL FIT TAMIYA TT01E EURO TRUCK)

How to calculate Final Gear Ratio?

For example, if your car has the following setting:

Motor Gear: 25

Spur Gear: 84

Pulley: 19

Gear Differential: 38

Firstly, we need to calculate the 'Motor Gear to Spur Gear Ratio', divide 84 by 25 equal to 3.36. Then we need to calculate the 'Pulley to Gear Differential Ratio', divide 38 by 19 equal to 2. Finally, the 'Final Gear Ratio' is 3.36 x 2 = 6.72.

Motor Turn used based on Final Gear Ratio:

3.5T: 9.5-10

4.0T: 8.9-9.5

8.5T: 6.4-7.0

The above guideline is for reference only. The recommended motor turn may vary depending on different brands. More information can be found on motors' offical websites.

Feature:

• Material: Aluminum 7075
• Color: Titanium

Include:

• Aluminum 7075 Hard Coated Motor Gear/Pinions 06P 19T (1 pc)
• Set screw (1 pc)
