Tamiya
(Discontinued) Tamiya - 1/10 RC Car Kit M-Chassis M-08R Chassis Kit - 47480 TAMIYA R/C KITS
£254.99
£299.99
-15%
The M-08R adds a plethora of race-spec parts to the balanced, compact RWD M-08 Concept chassis: an example being the hopped-up drivetrain with a ball differential, universal shafts featuring low-friction cross joints and lightweight aluminium swing shafts, plus 5mm wheel hubs. Turnbuckle shaft suspension arm and steering setup components simplify fine-tuning of the M-08R, and titanium-coated shafts are a durable inclusion in the kit. Carbon fibre damper stays are paired with M-Chassis big bore aluminium dampers+ featuring dedicated blue anodized top and bottom caps for a touch of class, while a 20-gram ballast weight is included to get the chassis feeling just how you want it to.
Featured Drivetrain Components
Chassis
Specifications
Separately Required Items
Photos of the Chassis
Featured Drivetrain Components
- Full ball bearings
- Ball differential (52T)
- 33mm lightweight aluminium swing shafts
- Cross joint for LF assembly type universal shafts
- 06 module fluorine coated 20T pinion gear
- M-08 Concept aluminium shafts
- M-Chassis reinforced freewheel axles
- 5mm clamp-type wheel hubs
- Suspension
- Carbon fibre damper stays (front/rear)
- Reinforced D parts (suspension arms)
- Aluminium turnbuckle shafts
- Titanium coated suspension shafts
- 5x5mm, 5x11mm hard hex head ball connectors
- M-Chassis big bore aluminium dampers+
- 3x 1.3mm-hole pistons
- 4mm aluminium serrated wheel nuts (blue)
- 5mm reinforced open face adjusters
Chassis
- Carbon fibre battery holder
- Carbon fibre body mount base
- Reinforced K parts (gearbox)
- Chassis balance weight (20g)
- Hi-torque servo saver
- Aluminium ball connectors (blue)
- Hex head screws
Specifications
- Scale is 1:10
- Length: 319mm (with 225mm wheelbase), width: 165mm
- Alterable wheelbase: 210mm, 225mm, 239mm
- Monocoque frame with separate front and rear sections
- Midship motor, rear-wheel drive
- Ball differential
- 3-piece steering tie-rod
- 4-wheel double wishbone suspension
- M-Chassis big bore aluminium dampers+
- Gear ratio = 5.776:1 (using kit 20T pinion); 8 ratios between 6.795:1 and 4.813:1 are possible with separately sold pinions)
- Electronic speed controller (ESC) is sold separately.
Separately Required Items
- Body
- Type 540 motor (brushless is recommended)
- Tyres
- 2-channel R/C system w/ESC
- R6/AA/UM3 batteries for transmitter
- Battery pack & charger
Photos of the Chassis
